Heat-Pump Dehumidifier DeAir.RE-1200

SPECIFICATION
  • Temperature range
(5 - 60)°C
  • Airflow rate
: 12,000 CMH
  • Dehumidifier capacity
: 1,200 kg/day
  • Nominal conditions
30°C, 70%
  • Power consumption
: 18.4 kW
  • Power source

: 380V/3 Ph/50Hz
  • Weight
: 500 kg
  • Refrigerant

: R410A
  • Dimensions (W x D x H)
: 1,750 x 800 x 1,800 mm
  • Noise

:  72 dBA

172.800.000 VNĐ 183.000.000 VNĐ - 5.6%
Quantity
Products of DEAIR . JSC

Heat-Pump Dehumidifier DeAir.RE-1200 solution for large spaces

Heat-Pump DeAir.RE-1200 Dehumidifier: Powerful, energy-saving industrial dehumidification solution for large spaces.





In the production environment, warehouse or commercial center, humidity control plays a key role in ensuring product quality, labor safety, and production efficiency. Too high humidity can cause mold, damage goods, affect the health of workers and reduce the life of machinery and equipment.

The DeAir.RE-1200 heat-pump industrial dehumidifier is the optimal solution to help you solve these problems.



1. Principle of operation

The operating principle of the Heat-Pump DeAir.RE-1200 dehumidifier



The DeAir.RE-1200 heat-pump dehumidifier applies the principle of dehumidification by using a refrigerant compressor. First, the compressor starts to compress the refrigerant. When the evaporator cools the air to a temperature lower than the air dew point, the water vapor will condense and adhere to the tray, and finally escape through the pipes. In a cycle, the humidity in the house gradually decreases. The dehumidifier can be used not only with the ventilation duct and damper, but also separately.



2. Outstanding advantages

Made in Vietnam with advanced technology, the DeAir.RE-1200 dehumidifier has the following advantages:



2.1. Powerful dehumidification performance



Heat-Pump DeAir.RE-1200 dehumidifier has a capacity of 1200l/day



  • Dehumidification capacity up to 1200 liters/day, meeting the need to control humidity for large spaces from 1000-2000m2.
  • Air flow 12000 m3/h, ensuring effective air circulation and dehumidification.
  • Intelligent control panel from 10-95%, meeting the diverse requirements of each industry.



2.2. Stable operation, energy saving



DeAir.RE-1200 Heat-Pump Dehumidifier saves energy

  • Power consumption is only 18.4kW, helping to save operating costs.
  • Standard noise level 72dBA, meets industrial standards, minimizes impact in quiet spaces.
  • Automatic water discharge pipe, making it easy for users to operate and maintain.



2.3. Flexible and convenient design



Heat-Pump DeAir.RE-1200 dehumidifier is easy to install and operate



  • Modern design in size 1,750x800x1,800 mm, weight 500kg, easy to install, move, operate and maintain.



3. Installation instructions

To install and operate the machine properly according to its design and meet technical requirements, we need to clearly understand the structure of the machine. Note the following locations:

  • Air inlet: is the line of humid air returning from the room to the machine.
  • Air outlet: is the line of dry air that has been treated and supplied back to the room.
  • Power source: is the location of the power supply wire for the machine to operate.
  • Drain pipe: is the exit position of the waste water pipe.
  • The installation of the machine must follow some notes to ensure the machine operates effectively and is convenient for maintenance and repair later.



4. Application



  • Production room: Maintain stable humidity, protect raw materials, machinery and equipment, create a safe and comfortable working environment for workers.

application of Heat-Pump DeAir.RE-1200 Dehumidifier in production room





  • Storage: Prevent mold, damage to goods, ensure product quality meets export standards.

Heat-Pump DeAir.RE-1200 dehumidifier in storage





  • Commercial area: control humidity, preserve fresh food, create a comfortable shopping space for customers.

Heat-Pump DeAir.RE-1200 dehumidifier in commercial area







5. Benefits of choosing DeAir



  • Made in Vietnam: products are designed and manufactured on demand, meeting the specific climate and individual needs of each customer.
  • 24/7 technical service: a team of experienced engineers is ready to support customers anytime, anywhere.
  • Periodic maintenance program: ensures stable machine operation and prolongs the life of the machine longevity.



DeAir.RE-1200 - The perfect choice for your industrial space.

Discover real projects that have effectively applied our dehumidifiers.

To better understand the product products and other applications, please watch more useful videos on DeAir's Youtube channel

Contact DeAir now to receive the best quote and advice on designing the optimal dehumidification system for your project.
