Dezenno Rotor Dehumidifier 1500CMH - 18000CMH

Dezenno Rotor Dehumidifier 1500 - 18000: Superior Humidity Control Solution

The Dezenno Rotor Dehumidifier 1500 - 18000 is an advanced solution designed to effectively control relative humidity (RH) and absolute humidity, especially suitable for industrial applications requiring extremely low humidity environments and preventing condensation. This technology meets the stringent demands of industries such as pharmaceuticals, electronics, food, storage (seeds, equipment), laboratories, and precision mechanics.

1. Structure of Dezenno Rotor Dehumidifier 1500 - 18000

The Dezenno rotor dehumidification system is designed with scientific air connection ports, including:

• Moist air inlet: Directs air to be dried into the unit.
• Dry air outlet: Delivers dried air to the target area.
• Regeneration air inlet: Directs hot air (usually heated fresh air) to regenerate the rotor's dehumidifying capacity.
• Moist exhaust air outlet (regeneration): Discharges the air stream carrying moisture removed from the rotor.

This design ensures continuous and efficient dehumidification, with precisely controlled airflow.

At the heart of the system is the desiccant rotor with a special honeycomb structure, formed by alternating layers of material (flat and corrugated sheets) impregnated with a high-grade desiccant, typically activated silica gel or zeolite materials. This structure creates countless parallel axial air channels, optimizing the contact area between humid air and the desiccant material, thereby enhancing drying efficiency.

In addition, the system also includes:

• Regeneration chamber: The area where the desiccant material is regenerated.
• Supply/exhaust fan: Ensures stable airflow through different sections of the unit.
• Rotor drive motor: Causes the rotor to continuously rotate, alternating between the dehumidification and regeneration zones.

2. Operating Principle of Dezenno Rotor Dehumidifier 1500 to 18000

The operating principle of the Dezenno rotor dehumidifier is based on the continuous process of **moisture adsorption**. The desiccant rotor slowly rotates through two distinct zones:

• Process zone: Humid air from the area to be dried is drawn through the rotor by a fan. The desiccant material (e.g., silica gel) on the rotor adsorbs water vapor, resulting in drier air exiting.
• Regeneration zone: The moisture-laden part of the rotor moves to this zone. Here, a stream of hot air (typically heated by an electric heater or other heat source) is blown through the rotor in the opposite direction. The high temperature desorbs the adsorbed water vapor, and this humid air is exhausted.

The continuous rotation of the rotor ensures the system's non-stop dehumidification capability.

3. Wide Application of Dezenno Rotor Dehumidifier with Capacity Range 1500 - 18000

As a highly efficient dehumidification solution, the Dezenno rotor dehumidifier is especially suitable for environments requiring extremely low and strict humidity, such as:

• Pharmaceuticals: Humidity control in the production of tablets, powders, packaging areas, storage of raw materials and finished products to ensure quality and shelf life.
• Electronics: Maintaining extremely low humidity in clean rooms for the production of semiconductor components, printed circuit boards (PCBs), preventing static electricity and oxidation.
• Food: Preserving flours, sugars, powdered milk, and cereals, preventing clumping and mold. Applied in low-temperature food drying to preserve quality.
• Warehouses: Protecting sensitive electronic equipment, important papers, documents, and artwork from humidity damage.
• Laboratories: Ensuring stable humidity for environmentally sensitive experiments, storage of chemicals and specimens.

Other industries:

• Battery Manufacturing: Controlling humidity during lithium-ion battery production to ensure performance and safety.
• Paints and Plastics: Maintaining proper humidity to ensure surface quality and adhesion.
• Paper: Preventing wrinkling and distortion of paper during production and storage.
• Aquaculture: Used in recirculating aquaculture systems (RAS) to control air quality and prevent fungal diseases.

Dezenno rotor dehumidifiers offer many outstanding benefits:

• Precise humidity control: Maintain a stable and extremely low humidity environment according to production or storage process requirements.
• Prevents condensation: Eliminates the risk of product and equipment damage due to water condensation.
• Protects product quality: Extends product lifespan, maintains physical and chemical properties.
• Improves productivity: Creates optimal working conditions, minimizes production downtime due to humidity issues.
• Smooth operation: Low noise, does not negatively affect the working environment.
• Energy saving: Optimized design for dehumidification and regeneration performance.
• High durability: Utilizes quality materials and advanced technology.
• Easy installation and maintenance: Modular design, convenient for operation and periodic maintenance.
• Cost-effective: Minimizes waste due to product damage, optimizes energy consumption.

4. Benefits of Choosing DeAir

• Made in Vietnam: Products are flexibly designed and manufactured, meeting the technical requirements and specific climate conditions of Vietnam, as well as customized to individual customer needs.
• Professional 24/7 technical service: A team of experienced, well-trained engineers and technicians are ready to support customers anytime, anywhere, ensuring stable system operation.
• Regular and comprehensive maintenance program: Ensures optimal equipment performance, extends lifespan, and reduces the risk of unexpected breakdowns.

With outstanding advantages in performance, reliability, and customizability, DeAir's Dezenno rotor dehumidifiers are the optimal humidity control and anti-condensation solution for demanding industrial applications.
